Model 6000 Digital

Introducing the Model 6000 Digital Mixer, one of Arrow Mixing Products‘ high-quality electric mixers designed for light-duty applications. With a maximum speed of 6000 rpm, this mixer is ideal for a variety of industrial mixing needs. Discover how the Model 6000 Digital Mixer can enhance your operations and why it stands out among other industrial mixers.

Key Features and Specifications

The Model 6000 Digital Mixer is packed with features that ensure efficient and reliable mixing:

• Max RPM: 6000
• Horsepower: 1/10
• Torque: 1.05 in-lbs
• Power: 120 VAC 60 Hz
• Consumption Amp: 0.8
• Batch Size (Water): 20 liters
• Gear Ratio: Direct
• Motor Shaft Diameter: 3/8″
• Motor Dimensions: Dimensional drawing available upon request
• Shipping Weight: 9 lbs (4.0 kg)

Standard components include:

• 3/8″ dia x 12″ propeller shaft (S-316-12)
• 2 1/2″ dia propeller (#25B)
• Aluminum Coupling (CPL22-375)
• 9/16″ dia x 10″ mounting rod (#15)
• 6ft Power cord with grounded plug (#POCO 120)

Enhanced Control and Safety

The Model 6000 Digital Mixer offers enhanced control and safety features that make it an excellent choice for precise and secure mixing tasks. Its direct gear ratio ensures consistent performance, while the durable construction of the propeller and shaft guarantees longevity. The grounded power cord adds an extra layer of safety, preventing electrical hazards during operation.

Why Choose the Model 6000 Digital Mixer?

Choosing the Model 6000 Digital Mixer means investing in a reliable and efficient mixing solution. Here’s why it stands out:

• Versatility: Suitable for a wide range of light-duty mixing applications.
• Efficiency: High-speed mixing with a maximum of 6000 rpm ensures quick and thorough blending.
• Durability: Built with high-quality materials that ensure long-lasting performance.
• Safety: Equipped with features that prioritize user safety during operation.
• Support: Backed by Arrow Mixing Products’ commitment to customer satisfaction and support.

Contact Arrow Mixing Products Today

Ready to enhance your mixing capabilities with the Model 6000 Digital Mixer? Contact Arrow Mixing Products today to learn more about this exceptional mixer and our other industrial mixing solutions. Our team is here to help you find the perfect equipment to meet your business needs. Reach out to us for additional information, a quote, or to discuss your specific requirements. Discover the difference that high-quality mixing equipment can make for your operations with Arrow Mixing Products!

This industrial mixer comes standard with:
3/8″ dia x 12″ propeller shaft (S-316-12)
2 1/2″ dia propeller (#25B)
Aluminum Coupling (CPL22-375)
9/16″ dia x 10″ mounting rod (#15)
6ft Power cord with grounded plug (#POCO 120)

Horsepower: 1/10
Batch size water: 20 liter
Description: Light Duty
Gear ratio: Direct
Max. rpm: 6,000
Torque: 1.05 in-lbs
Power: 120 VAC 60 Hz
Consumption amp: 0.8
Motor shaft dia.: 3/8″
Motor dimensions: dimensional drawing of overhead stirrers available upon request
Shipping Weight: 9 lbs (4.0 kg)

Shipping UPS in the United States only. Any other shipping should contact us.

Model 6000 Digital Manual
Download PDF
